S85 Aluminium
Window System
A minimal, thermally insulated outward-opening aluminium system engineered for contemporary architecture. SMARTIA S85 combines slim sightlines, flush surfaces, advanced weather performance and robust aluminium construction in an 85 mm platform.
Minimal architecture.
Serious performance.
ALUMIL SMARTIA S85 is a high-performance thermally insulated aluminium window system developed around the requirements of modern outward-opening architecture.
The system combines a frame and sash depth of 85 mm with a minimum visible aluminium face of only 68 mm, helping maximise the glazed surface while maintaining the structural integrity required for demanding contemporary building envelopes.
Its internally and externally flush profile geometry gives the window a clean architectural appearance, while outward opening leaves valuable interior space unobstructed.
With advanced EPDM sealing, thermally broken profiles and configurations designed for double or triple glazing, S85 provides a carefully balanced combination of aesthetics, energy performance, weather resistance and everyday functionality.
Minimal Sightlines
Only 68 mm minimum visible aluminium allows larger glazed areas and a clean architectural appearance.
Flush Design
Flat, flush internal and external surfaces create refined detailing suited to contemporary façades.
Outward Opening
The sash opens towards the exterior, preserving valuable usable space inside the building.
Weather Protection
Certified performance for air permeability, watertightness and resistance to wind pressure.
Designed to disappear into the architecture.
Contemporary windows should contribute to the architectural composition without visually dominating it. SMARTIA S85 focuses on restrained proportions, straight lines and reduced aluminium visibility.
The outward-opening configuration is particularly useful where architects want to preserve clean interior surfaces and avoid sash intrusion into living or working spaces.
Built beyond appearance.
The S85 platform is engineered not only as an architectural window, but as part of the building envelope. Its certified performance addresses air, water, wind and security requirements for demanding projects.
1.5 W/m²K Depending on system configuration.
2022 Security performance according to tested configuration.
50 kg Subject to dimensions and hardware configuration.
68 mm Reduced frame visibility for increased transparency.
SMARTIA S85
specifications
An 85 mm thermally insulated platform combining narrow sightlines with advanced sealing and high-performance glazing configurations.
Final values and permissible dimensions depend on typology, sash dimensions, hardware, glazing, exposure conditions and project engineering.
85 mm thermally insulated profile construction.
The S85 profile architecture combines aluminium rigidity with thermal-break technology and carefully engineered sealing zones.
The thermal separation of the inner and outer aluminium shells helps reduce heat transfer through the frame, while EPDM gasket sealing supports air and water resistance.
Depending on project requirements, glazing can be specified to address thermal performance, solar control, safety, security and acoustic objectives.
S85 Profile Section
Architecture and engineering working together.
Every part of S85 is designed around the relationship between architectural simplicity and technical performance.
Flush Surfaces
Internal and external profiles align to create a clean and contemporary architectural expression.
Thermal Break
Thermally insulated aluminium construction limits thermal transfer between exterior and interior surfaces.
Reduced Sightlines
A minimum aluminium face of 68 mm allows more daylight and a stronger visual connection outdoors.
Advanced Sealing
EPDM gaskets provide durable sealing against air infiltration and water penetration.
Energy-Efficient Glazing
Compatible configurations allow the integration of double or triple insulating glass units.
Secure Ventilation
Compatible system solutions can support controlled ventilation while maintaining increased security.
More freedom inside the room.
S85 opens towards the exterior, leaving the interior completely free from the sweep of a conventional inward-opening sash.
This architecture can be especially useful near furniture, countertops, work surfaces and other interior elements where unrestricted internal space is desirable.
Designed around modern high-performance glazing.
The performance of a window is determined by the complete assembly — aluminium frame, glazing, spacer, sealing, hardware and installation.
SMARTIA S85 supports double and triple glazing configurations, allowing the glass specification to be selected according to the thermal, solar, safety and architectural requirements of each project.
Efficient insulating glass solutions for residential and commercial applications.
Available where increased thermal performance is required and compatible with the selected system configuration.
Solar-control glazing can help manage excessive solar heat gain in exposed façades.
Laminated or toughened glass can be specified where safety or additional security is required.
Flexible typologies for architectural projects.
S85 can be incorporated into multiple fixed and operable configurations, depending on project design and structural requirements.
Where S85 fits best.
A refined solution for buildings where slim proportions, outward operation and reliable envelope performance are design priorities.
Precision fabrication for international projects.
Mparolas Aluminium Systems manufactures custom aluminium windows and doors in Greece for residential, commercial and international projects.
Each project is evaluated individually according to architectural drawings, opening dimensions, glass specification, wind exposure, energy requirements and destination.
Send Us Your Project →
ALUMIL SMARTIA S85 frequently asked questions
What is ALUMIL SMARTIA S85?
SMARTIA S85 is a thermally insulated outward-opening aluminium window system designed for modern architecture. It combines an 85 mm frame depth, flush profile geometry and a minimum visible aluminium face of 68 mm.
Is the ALUMIL S85 thermally broken?
Yes. SMARTIA S85 is a thermally insulated aluminium system designed to reduce heat transfer through the frame. The final overall window Uw value depends on dimensions, glazing, spacer and complete window configuration.
Does the SMARTIA S85 open inward or outward?
SMARTIA S85 is designed as an outward-opening system. This allows the sash to open towards the exterior without occupying interior space.
What glazing can be used with ALUMIL S85?
The system supports double and triple glazing. Maximum glazing thickness is up to approximately 28 mm or 44 mm depending on the selected configuration. Final glass selection should be determined according to thermal, safety, solar-control and project requirements.
What is the air permeability performance of S85?
The system has achieved Class 4 air permeability performance in the tested configuration.
What is the watertightness performance?
SMARTIA S85 has achieved Class E750 watertightness performance according to the system's tested configuration.
Is SMARTIA S85 suitable for exposed locations?
The system provides high tested air, water and wind performance, including Class C5/B5 wind-load resistance. However, suitability for a specific building should always be assessed according to opening dimensions, building height, orientation, exposure and local design loads.
Can Mparolas manufacture ALUMIL S85 windows for export?
Mparolas Aluminium Systems manufactures custom aluminium windows and doors in Greece and can support selected international projects with project-specific fabrication, glazing, technical coordination and export-ready packaging.
Considering ALUMIL S85 for your next project?
Send us your architectural drawings, opening schedules, dimensions and performance requirements. Our team can evaluate the project and propose the appropriate aluminium, glazing and fabrication configuration.
Technical values shown on this page refer to published ALUMIL SMARTIA S85 system data and tested configurations. Actual window performance, dimensions and permissible sash sizes may vary according to typology, glazing, hardware, fabrication, installation and project-specific conditions. Final specifications should always be confirmed during technical project evaluation.
